Hot Air Mesh Belt System Large Drying Production Line

Model Number:                Mesh Belt Dryer
Samples:                           $100.00/Set | 1 Set (Min. Order)
Customization:                 Customized logo(Min. Order: 5 Sets)
                                         Customized packaging(Min. Order: 5 Sets)
                                         Graphic customization(Min. Order: 5 Sets)
Availability:
Quantity:

Quick Details

  • Type:Belt Dryer

  • Application:                                       Food Processing, Food

  • Condition:                                          New

  • Place of Origin:                                 Sichuan, China

  • Brand Name:                                     ShouChuang

  • Voltage:                                             380V

  • Power:                                                20k

  • Dimension(L*W*H):                         Customized

  • Certification:                                     ISO SGS

  • Key Selling Points:                           Automatic

  • Warranty:                                           1 Year

  • After-sales Service Provided:         Online support, Field installation, commissioning and training, Field maintenance and repair service

  • After Warranty Service:                   Video technical support, Online support, Field maintenance and repair service

  • Applicable Industries:                      Manufacturing Plant, Farms

  • Local Service Location:                   None

  • Showroom Location:                           None

  • Marketing Type:                                    New Product 2020

  • Machinery Test Report:                       Provided

  • Video outgoing-inspection:                 Provided

  • Warranty of core components:          1 Year

  • Core Components:                               Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine, Pressure vessel

    • Name:                                                     Food Dryer

    • Material:                                                 Stainless Steel

    • Usage:                                                     Reduce Material's Moisture

    • Color:                                                      Silver

    • Installation:                                            Oversea Engineer Team

    • Package:                                                Wooden Case

    • Fuel:                                                        Electricity Etc

    • Function:                                                Food Vegetable Fruit Dehydrator

    • Delivery time:                                         30 Days



        Supply Ability

        • Supply Ability                                              400 Set/Sets per Year

        Packaging & Delivery

        • Packaging Details                                      Wooden case or Container

        • Port                                                               As you required

        • Lead Time:

        • Quantity(Sets) 1 - 5 >5
          Est. Time(days) 30 To be negotiated

        Working sites of drying machine

        1

        Working principle of drying machine

        The hot air circulation oven adopts the long shaft circulation fan with high temperature resistance. The forced hot air heated by the electric heating pipe or the steam heat exchanger circulates in the oven, which enhances the heat transfer, improves the water evaporation rate and shortens the drying time. The whole box adopts a fully enclosed structure, most of the hot air is circulated in the box, and the hot and humid air is reasonably discharged and fresh air is added, with high thermal efficiency and energy saving. Under the effect of forced ventilation, the materials are dried evenly. The oven is equipped with an automatic temperature control system, with accurate temperature control.

        2

        Application of shouchuang wide range of applications drying oven sites

        3

        Modern food drying not only pays attention to the taste of food,but also pays more and more attention to the nutrition of food.



        This rotary oven can satisfy the drying requirements of different foods without damaging the flavor substances,structure and various natural pigments and heat sensitive substances.



        At the same time,it also maximizes the storage of vitamins,carbohydrates,proteins and other nutrients in processed materials to meet the needs of modern people for the nutritional value of dried foods.



        ShouChuang dryer parameter





        Item

        SC-C1

        SC-C2

        SC-C3

        SC-C4

        SC-C5

        Drying area (m2)

        7.1

        14.1

        28.3

        42.4

        56.5

        Effective volume (m3)

        1.3

        2.6

        4.9

        7.4

        10.3

        Drying capacity(Kg/batch)

        60

        120

        240

        360

        480

        Fan air volume (m3/h)

        3450

        3450

        6900

        10350

        13800

        Fan power(KW)

        0.55

        0.55

        0.55×2

        0.55×3

        0.55×4

        Dryer dimension(mm)

        1410×1200×2160

        2250×1200×2160

        2250×2160×2160

        3290×2160×2160

        4360×2160×2160

        Trolley

        1

        2

        4

        6

        8

        Tray

        24

        48

        96

        144

        192

        Weight (Kg)

        480

        1080

        1520

        1960

        2400



        Advantages and eatures:

        1. The air supply and return part is connected with the drying room, and the target temperature is reached through multiple cycles, and the circulating air volume is not affected;

        2. Suitable for drying most materials;

        3. Common models: split type, closed type, integrated opening and closing.

        Sichuan Nanchong Shouchuang Technology Development Co., Ltd is a service provider focusing on comprehensive processing solutions for agricultural products.It is a high-tech enterprise.It is committed to helping customers solve the problem of storage and collection of agricultural products,put an end to processing pollution and preserve the quality of agricultural products.



        Processing flow

        5

        6
