SC high-tech new patent machinery product for chilly dry teja chilies s17 red chili powder machine


Quick Details

  • Applicable Industries:                Manufacturing Plant, Food & Beverage Factory, Food Shop, Food & Beverage Shops

  • After Warranty Service:              Video technical support, Online support, Field maintenance and repair service

  • Local Service Location:               None

  • Showroom Location:                  None

  • Video outgoing-inspection:       Provided

  • Machinery Test Report:              Provided

  • Marketing Type:                         New Product 2021

  • Warranty of core components: 1 Year

  • Core Components:                     PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump

  • Condition:                                  New

  • Place of Origin:                          Sichuan, China

  • Brand Name:                             Shouchuang dryer

  • Type:                                          chilli machine

  • Voltage:                                     380v

  • Power:                                      20kw

  • Weight:                                    10000kg-20000kg

  • Dimension(L*W*H):                 11000*2000*2000mm

  • Certification:                             CE/ISO/SGS

  • Year:                                         2021

  • Warranty:                                 1 Year, 1 year

  • After-sales Service Provided:   Field installation, commissioning and training, Engineers available to service machinery overseas

  • Name:                                       chilli machine

  • Function:                                   drying

  • Material:                                   304 Stainless Steel

  • Process material:                      Chilli

  • Advantage:                                Low Cost Fast Effect

  • Application:                              Chili Processing Line

  • Delivery time:                           Customized

  • Color:                                        grey

Packaging & Delivery

  • Selling Units:                               Single item

  • Single package size:                    40X64X10 cm

  • Single gross weight:                   100000.000 kg

    • Package Type:                             Wooden case or Container

    • Lead Time:

    • Quantity(Sets) 1 - 1 >1
      Est. Time(days) 35 To be negotiated


    Shouchuang SC  series drying machine components

    1.Heat exchange furnace.

    2.Heat exchange furnace draft fan with chimney.

    3.Fan (own brand fan).

    4.Chili drying equipment system (Food grade stainless steel,drying temperature 30~160 degree centigrade).

    5.Feeding conveyor.

    6.Discharge conveyor.

    7.Control panel.

    8.Remote control temperature and humidity control system.


    Working principle of shouchuang SC series drying machine

    The mesh belt type through flow dryer uses the hot air produced by the hot air stove / electric heating pipe as the drying medium, and transmits the hot air to the dryer through the hot air distribution parts to dry the materials. The processed materials are transported by the multi-layer movable stainless steel mesh belt, and the hot air flows through the mesh belt and the material layer on it from the bottom to the top, with multi-layer circulation and turnover, drying layer by layer, uniform heat exchange and charging Points, high production efficiency, good product quality.


    In the whole equipment, the hot air on-off and air volume, the speed of network belt operation, the temperature in the drying room and other states can be adjusted by the electric control system, achieving continuous production, greatly improving work efficiency, reducing labor intensity and saving labor cost.

    The advantage of shouchuang SC series drying machine

    1. For the whole processing line just need 1-2 people to operate.

    2. 45 years drying experience and have many sucess working sites can visit.

    3. It can be continuously produced in large quantities and keep the nutrition and color of the product to the maximum extent.

    4. According to the characteristics of capsicum, different technological processes and necessary auxiliary equipment can be added.

    5. More drying output, fast drying speed, high dry product efficacy, fuel saving, high thermal efficiency, good dry product color.

    6. Self owned patent technology dryer equipment, more than 50 national patent technologies, thousands of materials drying database.The unique air supply mode of the multi section pulse drying technology can prevent the damage of the material caused by the flooding drying.

    7. Stainless steel material and food grade conveyor to ensure the product reach hygienic standard.

    8. After the machine arrived and the seller will dispatch engineer to buyer's working sites help buyer install and adjust the drying machine until the machine achieve the best drying effect,then our engineer will back to our country.

    Mesh belt drying machine parameters


    Model SC-4*6 SC-4*7 SC-4*8 SC-4*9 SC-4*10 SC-4*12
    Layer 4 4 4 4 4 4
    Paving thickness 41m2 48m2 55m2 62m2 69m2 83m2
    Drying temperature 50-160℃
    Drying cycle 2-8 hours
    Dehumidification intensity(kg/24h)  4500-8000  8000-9500  9500-11000  11000-12500  12500-14000  15500-17000
    Total power of fan(kw)  15 15 18.5  22  22  30
    Total power(kw)  18.5  18.5  22  27.5  27.5  35.5
    Dimension(m)  6*2.2*2.7  7*2.2*2.7 8*2.2*2.7   9*2.2*2.7  10*2.2*2.7  12*2.2*2.7

    The chili dyer machine working sites
